15VA 230VAC 15V 1000mA PCB Transformer encapsulated

– Manufacturer: BREVE TUFVASSONS
– Type of transformer: encapsulated
– Power: 15VA
– Primary voltage: 230V AC
– Secondary voltage 1: 15V
– Secondary winding current 1: 1000mA
– Mounting: PCB
– IP rating: IP00
– Conform to the norm:
PN-EN 61558-2-6:2000,
PN-EN 61558-2-1:2000,
PN-EN 61558-1:2000
– Thermal class: Ta60B
– Secondary winding terminals: 8-11
– Primary winding terminals: 1-6
– Weight: 450g
– A dimension: 44mm
– A1 dimension: 27.5mm
– A2 dimension: 25mm
– B dimension: 52mm
– C dimension: 41.5mm
– Electrical insulation strength:
4kV/60s

Additional information
– Gross weight: 373.1 g
