230VAC -15VAC 10VA PCB 667mA TRANSFORMER
€14,50
In stock
Description
– Manufacturer: MYRRA
– Type of transformer: encapsulated
– Power: 10VA
– Primary voltage: 230V AC
– Secondary voltage 1: 15V
– Secondary winding current 1: 0.667A
– Mounting: PCB
– Thermal class: T 50B
– Secondary winding terminals: 8-11
– Primary winding terminals: 1-6
– Body dimensions: 50.5×42.5×34.75mm
– Electrical insulation strength: 4kV/60s
Specifications
- Manufacturer: MYRRA
- Type of transformer: encapsulated
- Power: 10VA
- Primary voltage: 230V AC
- Secondary voltage 1: 15V
- Secondary winding current 1: 0.667A
- Mounting: PCB
- Thermal class: T 50B
- Secondary winding terminals: 8-11
- Primary winding terminals: 1-6
- Body dimensions: 50.5x42.5x34.75mm
- Electrical insulation strength: 4kV/60s
