24VAC 10A relay electromagnetic
€11,00
In stock
– Manufacturer: FINDER
– Type of relay: electromagnetic
– Contacts configuration: SPDT
– Rated coil voltage: 24V AC
– AC contacts rating @R
at resistance load: 10A / 250V AC
– DC contacts rating @R
at resistance load: 10A / 30V DC
– Contact current max.: 20A
– Switched voltage: max. 220V DC, max. 400V AC
– Relay variant: miniature
– Mounting: PCB, socket
– Coil resistance: 320Ω
– Body dimensions: 29×12.4x25mm
– Coil power consumption: 1.2VA
– Operating temperature: -40…85°C
– Relay series: 40.31
– Contact material: AgNi
– Terminal pitch: 3.5mm
– Coil current: 45mA
Additional information
– Gross weight: 16.89 g
