24VDC 12A ELECTR. RELAY UCOIL SPDT
€7,30
In stock
– Manufacturer: OMRON Electronic Components
– Type of relay: electromagnetic
– Contacts configuration: SPDT
– Rated coil voltage: 24V DC
– Contact current max.: 12A
– AC contacts rating @R: 12A / 250V AC
– DC contacts rating @R: 12A / 24V DC
– Manufacturer series: G2RL
– Switched voltage: max. 300V DC, max. 440V AC
– Relay variant: miniature
– Mounting: PCB
– Coil resistance: 1.44kΩ
– Operate time: 15ms
– Body dimensions: 29×12.7×15.7mm
– Release time: 5ms
– Contact resistance: 100mΩ
– Terminal pitch: 3.5mm
– Coil current: 16.7mA
– Leads: for PCB
– Enclosure description: standard seal
– Operating temperature: -40…85°C
