24VDC-COIL 5A/250VAC Relay electromagnetic
€3,60
Out of stock
– Manufacturer: RAYEX ELECTRONICS
– Type of relay: electromagnetic
– Contacts configuration: DPDT
– Rated coil voltage: 24V DC
– AC contacts rating @R
at resistance load: 5A / 250VAC
– DC contacts rating @R
at resistance load: 5A / 30VDC
– Contact current max.: 5A
– Switched voltage: max 30V DC, max 250V AC
– Relay variant: miniature
– Mounting: PCB
– Coil resistance: 1.1kΩ
– Operate time: 15ms
– Body dimensions: 29 x 20.5 x 12.5mm
– Release time: 10ms
– Coil power consumption: 530mW
– Operating temperature: -40…80°C
– Relay series: LM2
– Contact resistance: 100mΩ
– Contact material: AgCdO
– Terminal pitch: 5mm
– Coil current: 21.8mA
Additional information
– Gross weight: 0.01 kg
