6-Way splitter 2400 MHz

Description: 6-Way Splitter, Indoor use
Order Number: 2078

Frequency Range
– Frequency range: 5~2400 MHz

Insertion Loss In-Out
– Insertion loss 5~862 MHz: ≤ 11.8 dB
– Insertion loss 950~1550 MHz: ≤ 13.5 dB
– Insertion loss 1551~2150 MHz: ≤ 15.1 dB
– Insertion loss 2151~2400 MHz: ≤ 15.1 dB

Isolation Out-Out
– Isolation 5~300 MHz: ≥ 28 dB
– Isolation 301~862 MHz: ≥ 25 dB
– Isolation 950~2400 MHz: ≥ 25 dB

Physical
– Connectors type: F-female

Electrical Data
– Impedance: 75 Ohm
– DC pass-through: Yes
