AMASS MT30-F DC 3PIN Female For Cable Sol. 15 A

AMASS MT30-F DC 3PIN Female For Cable Sol. 15 A

AMASS MT30-F dc power socket. rated current: 15 A; rated voltage: 500 V; colour: Yellow.

Specifications

• Item code: MT30-F
• Product type: DC Power Socket
• Brand: AMASS
• Rated current: 15 A
• Rated voltage: 500 V
• Mounting: for cable
• Termination: soldering
• Orientation: straight
• Colour: Yellow
• Material: polyamide
• – Manufacturer: AMASS
  – Connector: plug
  – Type of connector: DC supply
  – Connector series: MT30
  – Kind of connector: female
  – Number of pins: 3
  – Mechanical mounting: for cable
  – Electrical mounting: soldering
  – Contact plating: gold flash
  – Colour: yellow
  – Current rating: 15A
  – Flammability rating: UL94V-0
  – Operating temperature: -20…120°C
  – Rated voltage: 500V
  – Spatial orientation: straight
  – Contact material: brass
  – Mechanical durability: 1000 cycles
  – Body material: polyamide
  – Wire size: 16AWG

  Additional information
  – Gross weight: 1.66 g

Περιγραφή στα Ελληνικά

AMASS MT30-F: Υποδοχή τροφοδοσίας DC. Ονομαστικό ρεύμα: 15 A; Ονομαστική τάση: 500 V; Χρώμα: Κίτρινο.
