ELECT. RELAY 48VDC 6A/250VDC 4PDT
€17,75
Out of stock
– Manufacturer: TE Connectivity
– Type of relay: electromagnetic
– Contacts configuration: 4PDT
– Rated coil voltage: 48V DC
– Contact current max.: 6A
– AC contacts rating: 6A / 250V AC
– DC contacts rating: 6A / 30V DC
– Switched voltage: max. 250V AC, max. 300V DC
– Relay variant: industrial
– Mounting: socket
– Relay series: PT
– Operating temperature: -40…70°C
– Body dimensions: 28×22.5x30mm
– Coil resistance: 3072Ω
– Contact material: AgNi
– Coil power consumption: 0.75W
– Optional equipment: test button with blocking function
– Related items: PT78740
