ELECTR. RELAY 9VDC 8A SPSI
€3,30
In stock
– Manufacturer: GOODSKY
– Type of relay: electromagnetic
– Contacts configuration: SPST-NO
– Rated coil voltage: 9V DC
– Contact current max.: 8A
– AC contacts rating: 8A / 250V AC
– DC contacts rating: 8A / 30V DC
– Relay series: JE
– Switched voltage: max. 30V DC, max. 440V AC
– Relay variant: miniature
– Mounting: PCB
– Coil resistance: 405Ω
– Body dimensions: 20x10x10.5mm
– Coil power consumption: 200mW
– Operating temperature: -40…85°C
– Contact material: AgNi
– Terminal pitch: 7.62mm
– Coil current: 22.2mA
- Manufacturer: GOODSKY
- Type of relay: electromagnetic
- Contacts configuration: SPST-NO
- Rated coil voltage: 9V DC
- Contact current max.: 8A
- AC contacts rating: 8A / 250V AC
- DC contacts rating: 8A / 30V DC
- Relay series: JE
- Switched voltage: max. 30V DC, max. 440V AC
- Relay variant: miniature
- Mounting: PCB
- Coil resistance: 405Ω
- Body dimensions: 20x10x10.5mm
- Coil power consumption: 200mW
- Operating temperature: -40...85°C
- Contact material: AgNi
- Terminal pitch: 7.62mm
- Coil current: 22.2mA
