MICROSWITCH SNAP ACTION WITH LEVER ON/ON
€29,75
Out of stock
– Manufacturer: Marquardt
– Manufacturer series: 1040
– Type of switch microswitch: SNAP ACTION
– Switches features: with lever
– Contacts configuration: SPDT
– AC contacts rating @R
at resistance load: 4A / 250V AC
– AC contacts rating @L
at inductive load: 1A / 250V AC
– Switching method
item in brackets is instantaneous: ON-ON
– Number of positions: 2
– Stable positions number: 1-position
– IP rating: IP40
– Leads: 2,8×0,8mm connectors, for soldering
– Body dimensions: 32x12x17.5mm
– Operating temperature: -35…85°C
– Operating Force: 0.9N
– Contact plating: silver plated
Additional information
– Gross weight: 7.8 g
