Pluggable terminal block male 2ways 7.5mm
€0,80
Out of stock
– Manufacturer: DEGSON ELECTRONICS
– Type of connector: pluggable terminal block
– Connector: socket
– Kind of connector: male
– Current rating: 20A
– Rated voltage: 400V
– Number of pins: 2
– Spatial orientation: angled 90°
– Mechanical mounting: on PCBs
– Electrical mounting: THT
– Contact material: brass
– Contact plating: tinned
– Colour: green
– Flammability rating: UL94V-0
– Body material: polyamide 66
– Depth: 12.1mm
– Connector pinout layout: 1×2
– Contacts pitch: 7.5mm
– Number of ways: 2
– Locking system: latch
– Conform to the norm: CE
UL
VDE
– Height: 8.2mm
– Operating temperature: -40…105°C
- Manufacturer: DEGSON ELECTRONICS
- Type of connector: pluggable terminal block
- Connector: socket
- Kind of connector: male
- Current rating: 20A
- Rated voltage: 400V
- Number of pins: 2
- Spatial orientation: angled 90°
- Mechanical mounting: on PCBs
- Electrical mounting: THT
- Contact material: brass
- Contact plating: tinned
- Colour: green
- Flammability rating: UL94V-0
- Body material: polyamide 66
- Depth: 12.1mm
- Connector pinout layout: 1x2
- Contacts pitch: 7.5mm
- Number of ways: 2
- Locking system: latch
- Conform to the norm: CE
UL
VDE
- Height: 8.2mm
- Operating temperature: -40...105°C
