Potentiometer 2.5k 250mW mounting single turn,horizontal
€1,85
In stock
– Manufacturer: PIHER
– Type of potentiometer: mounting
– Kind of potentiometer: horizontal, single turn
– Resistance: 2.5kΩ
– Power: 0.25W
– Tolerance: ±20
– Characteristics: linear
– Manufacturer series: PT15NV
– Potentiometer standard: 15mm
– Mechanical rotation angle: 265 ±5°
– Torque: 0,5…2,5Ncm
– Max. operating voltage: 250V
– Operating temperature: -25…70°C
– Mounting: THT
– Track material: carbon
– Terminal pitch: 12.5x10mm
– Electrical rotation angle: 250 ±20°
– Body dimensions: Ø15x6mm
- Manufacturer: PIHER
- Type of potentiometer: mounting
- Kind of potentiometer: horizontal, single turn
- Resistance: 2.5kΩ
- Power: 0.25W
- Tolerance: ±20
- Characteristics: linear
- Manufacturer series: PT15NV
- Potentiometer standard: 15mm
- Mechanical rotation angle: 265 ±5°
- Torque: 0,5...2,5Ncm
- Max. operating voltage: 250V
- Operating temperature: -25...70°C
- Mounting: THT
- Track material: carbon
- Terminal pitch: 12.5x10mm
- Electrical rotation angle: 250 ±20°
- Body dimensions: Ø15x6mm
