TRANSFORMER 2X6V 10VA 230V INPUT PCB

– Manufacturer: MYRRA
– Type of transformer: encapsulated
– Power: 10VA
– Primary voltage: 230V AC
– Secondary voltage 1: 6V
– Secondary voltage 2: 6V
– Secondary winding current 1: 0.833A
– Secondary winding current 2: 0.833A
– Mounting: PCB
– Thermal class: T 50B
– Secondary winding terminals: 7-8, 11-12
– Primary winding terminals: 1-6
– Body dimensions: 50.5×42.5×34.75mm
– Electrical insulation strength: 4kV/60s
