VANDAL RESIS. SWITCH OFF-ON 2A/36VDC
€6,80
Out of stock
– Manufacturer: ONPOW
– Type of switch: vandal resistant
– Number of positions: 2
– Contacts configuration: SPST-NO
– DC contacts rating @R
at resistive load: 2A / 36V DC
– IP rating: IP65
– Switching method
the position in bracket indicates momentary position.: OFF-ON
– Illumination: none
– Leads: screw terminals
– Operating temperature: -20…55°C
– Electrical life: 200000 cycles
– Max. contact resistance: 50mΩ
– Operating Force: 4N
– Mechanical durability: 1000000 cycles
– Button shape: prominent
– Mounting hole diameter: Ø16mm
– Body colour: black
– Body material: aluminium
– Ring shape: rounded
– Test voltage: 2kV
– Contact material: silver alloy
– Stable positions number: 1
Additional information
– Gross weight: 10.5 g
